Airbridge

Airbridge offers people-based attribution and incrementality measurement to measure and analyze true marketing effectiveness across devices, identities, and platforms.

The Braze and Airbridge integration lets you pass all organic and non-organic install attribution data to Braze to build personalized marketing campaigns and understand exactly where users were acquired.

Prerequisites

Requirement Description
Airbridge account An Airbridge account is required to take advantage of this partnership.
iOS or Android app This integration supports iOS and Android apps. Depending on your platform, code snippets may be required in your application.
Airbridge SDK In addition to the required Braze SDK, you must install the Airbridge Android or iOS SDK.

Integration

Integrating Airbridge to Braze will be made via SDK-to-SDK. Attribution data collected by the Airbridge SDK will be transmitted to Braze via the Braze SDK. Include the following code snippet into your Android or iOS application.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
AirbridgeConfig config = new AirbridgeConfig.Builder(BuildConfig.AIRBRIDGE_APP_NAME, BuildConfig.AIRBRIDGE_APP_TOKEN)
        .setOnAttributionResultReceiveListener(new OnAttributionResultReceiveListener() {
            @Override
            public void onAttributionResultReceived(Map<String, String> result) {
                AttributionData data = new AttributionData(
                    result.get("attributedChannel"),
                    result.get("attributedCampaign"),
                    result.get("attributedAdGroup"),
                    result.get("attributedAdCreative")
                );

                Braze.getInstance(applicationContext).getCurrentUser().setAttributionData(data);

                // NOTE: Data point will be consumed
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_ad_content", result.get("attributedContent"));
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_term", result.get("attributedTerm"));
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_sub_id", result.get("attributedSubPublisher"));
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_sub_id_1", result.get("attributedSubSubPublisher1"));
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_sub_id_2", result.get("attributedSubSubPublisher2"));
                Braze.getInstance(applicationContext).getCurrentUser().setCustomUserAttribute("airbridge_sub_id_3", result.get("attributedSubSubPublisher3"));
            }
        })
        .build();
Airbridge.init(this, config);
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
val config = AirbridgeConfig.Builder(BuildConfig.AIRBRIDGE_APP_NAME, BuildConfig.AIRBRIDGE_APP_TOKEN)
        .setOnAttributionResultReceiveListener(object : OnAttributionResultReceiveListener {
            override fun onAttributionResultReceived(result: Map<String, String>) {
                val data = AttributionData(
                    result["attributedChannel"],
                    result["attributedCampaign"],
                    result["attributedAdGroup"],
                    result["attributedAdCreative"]
                )

                Braze.getInstance(applicationContext).currentUser?.setAttributionData(data)

                // NOTE: Data point will be consumed
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_ad_content", result["attributedContent"])
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_term", result["attributedTerm"])
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_sub_id", result["attributedSubPublisher"])
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_sub_id_1", result["attributedSubSubPublisher1"])
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_sub_id_2", result["attributedSubSubPublisher2"])
                Braze.getInstance(applicationContext).currentUser?.setCustomUserAttribute("airbridge_sub_id_3", result["attributedSubSubPublisher3"])
            }
        })
        .build()
Airbridge.init(this, config)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
@UIApplicationMain
class AppDelegate: UIResponder, UIApplicationDelegate {
    func application(_ application: UIApplication,
                     didFinishLaunchingWithOptions launchOptions: [UIApplication.LaunchOptionsKey: Any]?) -> Bool {
        AirBridge.setting()?.attributionCallback = { attribution in
            let data = ABKAttributionData(network: attribution["attributedChannel"],
                                          campaign: attribution["attributedCampaign"],
                                          adGroup: attribution["attributedAdGroup"],
                                          creative: attribution["attributedAdCreative"])

            // NOTE: Data point will be consumed
            Appboy.sharedInstance()?.user.attributionData = data

            [
                "attributedContent": "airbridge_content",
                "attributedTerm": "airbridge_term",
                "attributedSubPublisher": "airbridge_sub_id",
                "attributedSubSubPublisher1": "airbridge_sub_id_1",
                "attributedSubSubPublisher2": "airbridge_sub_id_2",
                "attributedSubSubPublisher3": "airbridge_sub_id_3",
            ].forEach { (key, brazeKey) in
                guard let value = attribution[key] else {
                    return
                }

                Appboy.sharedInstance()?.user.setCustomAttributeWithKey(brazeKey, andStringValue: value)
            }

            Appboy.sharedInstance()?.flushDataAndProcessRequestQueue()
        }

        AirBridge.getInstance("YOUR_APP_TOKEN", appName: "YOUR_APP_NAME", withLaunchOptions: launchOptions)

        return true
    }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
@implementation AppDelegate

- (BOOL)application:(UIApplication *)application didFinishLaunchingWithOptions:(NSDictionary *)launchOptions {
    AirBridge.setting.attributionCallback = ^(NSDictionary<NSString*, NSString*>* _Nonnull attribution) {
        ABKAttributionData* data = [[ABKAttributionData alloc] initWithNetwork:attribution[@"attributedChannel"]
                                                                      campaign:attribution[@"attributedCampaign"]
                                                                       adGroup:attribution[@"attributedAdGroup"]
                                                                      creative:attribution[@"attributedAdCreative"]];
        [Appboy.sharedInstance.user setAttributionData:data];

        // NOTE: Data point will be consumed
        NSDictionary* keyMap = @{
            @"attributedContent": @"airbridge_content",
            @"attributedTerm": @"airbridge_term",
            @"attributedSubPublisher": @"airbridge_sub_id",
            @"attributedSubSubPublisher1": @"airbridge_sub_id_1",
            @"attributedSubSubPublisher2": @"airbridge_sub_id_2",
            @"attributedSubSubPublisher3": @"airbridge_sub_id_3",
        };

        for (NSString* key in keyMap.allKeys) {
            NSString* brazeKey = keyMap[key];
            NSString* value = attribution[key];

            [Appboy.sharedInstance.user setCustomAttributeWithKey:brazeKey andStringValue:value];
        }

        [Appboy.sharedInstance flushDataAndProcessRequestQueue];
    };

    [AirBridge getInstance:"YOUR_APP_TOKEN" appName:"YOUR_APP_NAME" withLaunchOptions:launchOptions];

    return YES;
}

@end

Available data fields

Airbridge can send seven types of data to Braze listed in the following data field chart. This data can be viewed in the Airbridge dashboard and is used for user install attribution, custom attribution, and filtering.

In addition to the four basic data types (Source, Campaign, Ad Group, and Ad) provided by Braze, Airbridge offers three additional data types such as airbridge_content, airbridge_sub_id, and airbridge_term as a custom attribute. Among these, airbridge_sub_id delivers a keyword to the value when it comes from search ads.

Airbridge data field Braze segment filter Type Description
attributedChannel Install Attribution Source Install Attribution Data Name of paid ad channel
attributedCampaign Install Attribution Campaign Install Attribution Data Name of campaign
attributedAdGroup Install Attribution Ad Group Install Attribution Data Name of adGroup
attributedAdCreative Install Attribution Ad Install Attribution Data Name of adCreative
attributedContent
(Optional)
airbridge_content Custom User Attribute Name of ad copy, slogan, and promotion
attributedTerm
(Optional)
airbridge_term Custom User Attribute Type of medium
attributedSubPublisher
(Optional)
airbridge_sub_id Custom User Attribute Ad search keyword
attributedSubSubPublisher1
(Optional)
airbridge_sub_id_1 Custom User Attribute
attributedSubSubPublisher2
(Optional)
airbridge_sub_id_2 Custom User Attribute
attributedSubSubPublisher3
(Optional)
airbridge_sub_id_3 Custom User Attribute

Facebook attribution data

Attribution data for Facebook campaigns is not available through our partners. This media source does not permit their partners to share attribution data with third parties and, therefore, our partners cannot send that data to Braze.

Airbridge click tracking URLs in Braze (optional)

Using click tracking links in your Braze campaigns will allow you to easily see which campaigns are driving app installs and re-engagement. As a result, you’ll be able to measure your marketing efforts more effectively and make data-driven decisions on where to invest more resources for the maximum ROI.

To get started with Airbridge click tracking links, visit the documentation found here. Once set up, you can directly insert the Airbridge click tracking links into your Braze campaigns. Airbridge will then use its probabilistic attribution methodologies to attribute the user that has clicked on the link. We recommend appending your Airbridge tracking links with a device identifier to improve the accuracy of attributions from your Braze campaigns. This will deterministically attribute the user that has clicked on the link.

For Android, Braze allows customers to opt-in to Google Advertising ID collection (GAID). The GAID is also collected natively through the Airbridge SDK integration. You can include the GAID in your Airbridge click tracking links by utilizing the following Liquid logic:

1
2
3
{% if most_recently_used_device.${platform} == 'android' %}
aifa={{most_recently_used_device.${google_ad_id}}}
{% endif %}

For iOS, both Braze and Airbridge automatically collect the IDFV natively through our SDK integrations. This can be used as the device identifier. You can include the IDFV in your Airbridge click tracking links by utilizing the following Liquid logic:

1
2
3
{% if most_recently_used_device.${platform} == 'ios' %}
idfv={{most_recently_used_device.${id}}}
{% endif %}
